PART #:
302-55W Terminations / Loads
DC-4200MHz, IP67
DESCRIPTION
302-5 Series of RF Terminations can be used for a broad range of applications operating from DC to 4200 MHz and is rated at 5 Watts power. These are precision machined, robust and can be used over a wide range of temperature and environmental conditions. They are perfect for both Indoor and Outdoor DAS applications.
FEATURES
- Superior Mechanical Construction
- 5 Watts Power Handling
- Low VSWR from DC to 4200MHz
- RoHS Complaint
- In stock and available immediately
- Available in DIN, Mini-DIN, 4.3-10 or Type-N Connectors
*** ORDERING INFO:
Part #: 302-5-*
(* - Connector Option)
APPLICATIONS:
- Indoor & Outdoor DAS
- Wi-Fi / WiMAX
- Cellular and GPS
- Communication Transmitter and Receiver
- Public Safety and ISM
- Instrumentation
ELECTRICAL & MECHANICAL SPECIFICATIONS:
| Frequency Range: | DC – 4200 MHz |
| VSWR | ≤ 1.25 (Typ) |
| Input power: | 5 Watts (Avg) |
| Impedance: | 50 Ω |
| Connectors Options: | 7/16 DIN (D) Mini-DIN (MD) 4.3-10 (D43) Type-N (N) |
| Housing Finish: | Aluminum Body |
| Mounting Method: | Mounting Panel |
| Temperature Range: | -35°C to 75°C |
| Weight: | 0.40lbs |
| Relative Humidity: | 5% - 95% |
| Environment: | IP67 |
Please contact our sales department at 737-200-7090 or sales@InnowaveRF.com for any custom requirements.
