932C-3500-3800

n77 Band (DoD, CBRS and C-Band) Combiner / Triplexer

-161dBc PIM, IP67, Stacked Model

FEATURES

  • Splits or combines the DoD Band (3450MHz-3550MHz), CBRS Bands (3560MHz-3690MHz) and C-Band (3700MHz-4200MHz)
  • Available in Single Model (931C Series)
  • Minimum 37dB Isolation between the bands
  • Very low Insertion Loss with superior out of band rejections
  • Available in 4.3-10 or NEX10 Connectors
  • Ease of Mounting with mounting holes and brackets
  • Low-PIM with High Power Handling
  • RoHS Compliant
  • Weatherproof for Outdoor installation
  • In Stock and Available Immediately

Electrical Specification

Frequency BandsPort 1Port 2 (CBRS)Port 3 (LTE-LAA)
-1,900,210,023,002,5003400-3800 MHz5150-5925 MHz
1695-2690 MHz
Passband Insertion Loss0.25 dB
Isolation≥ 40dB @ 3400-3800 MHz≥ 40dB @ 1695-2690 MHz≥ 40dB @ 1695-2690 MHz
≥ 40dB @ 5150-5925 MHz≥ 40dB @ 5150-5925 MHz≥ 40dB @ 5150-5925 MHz
Return Loss20 dB
Impedance50 Ohms
Input Power100 Watts (Avg)10W (Avg)10W (Avg)
Intermodulation (PIM - 3rd)-161dBc (2 Tones +43 dBm)
DC Pass Current3000mA (Typ) Pass-Through on Port1
Lightning Protection8/20S 10kA Pulse (IEC 801-5)
MTBF Hours≥ 500,000

MECHANICAL SPECIFICATIONS

Connectors4.3-10 (D43) / NEX10 (X10)
Housing FinishAluminum Body
Mounting MethodMounting Bracket
Temperature Range-30°C to 75°C
Humidity5% – 95%
Weight9.00 lbs
EnvironmentIP67

© Innowave RF, LLC. All Rights Reserved. Specs can change without notice. Drawings are for reference purpose only
